Administration

Log File

The log file, ppp.log, is written to by the LCS60 PPP server and contains information about incoming PPP call requests. To display the contents of the log file, use the page command as shown in the example below:

# pg /usr/adm/lcs/ppp.log
Fri Feb 16 11:32:55 13714	[3]	ppp1	NEW 1.1 dkserver=morse dk=mlkway/earth/ \
inbound.54.6 ch=508 uid=tbaker			rqst_reserved=1
Fri Feb 16 11:34:22 13714	[3]	ppp1	DEL 1.1
Tue Feb 20 13:34:25 13714	[3]	ppp1	NEW 1.1 dkserver=morse dk=mlkway/earth/ \
yardnac.65.3 ch=510 uid=pdavison rqst_reserved=1
Tue Feb 20 13:40:01 13714	[3]	ppp1	DEL 1.1
Tue Feb 20 13:54:49 13714	[3]	ppp1	NEW 1.1 dkserver=morse dk=mlkway/earth/ \
yardnac.65.3 ch=510 uid=pdavison rqst_reserved=1
Tue Feb 20 15:42:47 13714	[3]	ppp1	NEW 1.3 dkserver=morse dk=mlkway/earth/ \
yardnac.65.3 ch=508 uid=troughtn rqst_reserved=1
Tue Feb 20 15:51:52 13714	[3]	ppp1	DEL 1.3
Tue Feb 20 15:52:45 13714	[3]	ppp1	NEW 1.4 dkserver=morse dk=mlkway/earth/ \
yardnac.65.3 ch=508 uid=troughtn rqst_reserved=1
Tue Feb 20 15:54:12 13714	[3]	ppp1	DEL 1.4
Wed Feb 21 08:33:52 13714	[3]	ppp1	DEL 1.1
Wed Feb 21 08:33:53 13714	[3]	ppp1	exited
Wed Feb 21 10:32:25 489	[3]	ppp1	started loglevel = 3
Wed Feb 21 10:32:25 489	[3]	ppp1	nfiles=256
Wed Feb 21 11:04:15 388	[3]	ppp1	p3m received HANGUP for protocol: 802b
			∙
			∙

Related Commands

The following commands may be of particular interest when administering the LCS60's PPP service:

∙ ping	∙ ipxping	∙ atping
∙ netstat	∙ ipxnetstat	∙ atnetstat

PPP

The manual pages for these commands are contained in Appendix E of this docu- ment; they are also available online.
