Typical Administrative Tasks

Log Level Example

The following screen shows the user setting the log level for PPP.

Top>Manager>Server># log ppp 3

Top>Manager>Server>#

Change the Default Route Example

Top>Config># dftroute
CURRENT default route is .......	154.12.21.3

DEFAULT ROUTE FUNCTIONS

====================================================

1 ... Define the default route

2 ... Delete the default route

To select a function, enter the corresponding number [ Type q to quit or ? for help]

==> 1

CAUTION: The default route defined here will be overridden if a router is advertising a default route in the network.

Enter default router (name, alias, or internet address) [ Type q to quit or ? for help ]

==> 154.12.21.86

Trying to reach host "154.12.21.86" ... OK.

CURRENT default		route	is .......	holmes
NEW	default	route	will be ..	154.12.21.86

Enter y to confirm NEW default route "154.12.21.86" Enter n to reject NEW default route "154.12.21.86" ==> y

An example of changing the default route from holmes (154.12.21.3) to154.12.21.86is shown above.

Administration

Issue 3

8-23
