LCS60 Configuration and Connection for SLIP Service

Figure 5-1 shows an example network using SLIP service.

Figure 5-1: Example Network – SLIP Service

Lucent Data Switch

Modem Pool Mac

Remote Access Clients

LCS60

LAN

}

LCS200

Router

You can configure the LCS60 for SLIP service using either the srvsetup command or the individual commands (protocol, maxsessions, ipas, etherif). The examples in this chapter use the individual commands.

If previous configuration (for example, for PPP service) has been performed, some of the steps required for configuring LCS60 for SLIP service may have already been completed (e.g., etherif, ipas). Skip the steps that have been completed previously.

Note: The user should familiarize him/herself with all aspects of the LCS60 SLIP service. For details, including a description of Multiple IP Subnet- works, refer to Chapter 1.

After configuring the LCS60 as described under Initial Setup in Chapter 3, perform the steps shown in Figure 5-2 to configure the LCS60 SLIP Service.

SLIP

Issue 3 5-1
