Glossary

Ports DirectoryShow Statistics

Top>Ports> show

Port # The number of the configured port.

Service The service configured on the specified port (i.e., directory, telnet, socket).

State The state of the port service (up or down).

Total The number of times the port has been accessed.

Busy The number of times the port has been busy when access has been attempted.

Fail The number of times port access has been tried and failed.

Reset The number of times the port has been reset.

Show Configurations

Top>Ports> show -c

Glossary

Port #	The number of the configured port.
Service	The service configured on the specified port.
Tcpws	The window size configured for the port.
8-bit	Indicates whether the service port is configured with this option
	enabled (on) or disabled (-).

G-16

Issue 3
