HP LCS60 ask, @LABEL, matchread, matchstr 1, write “ATDTˆ1”, @ORIGINATE @ANSWER, note “Dialing ˆ 1”, Screen F-1: Continued

Client Software Configuration

Screen F-1: Continued

!

@LABEL 59

exit -6019

!

!Attempt to hang up the modem

@HANGUP exit 0

User Information

Edit this script with the information appropriate for your modem and configuration. The entries in the above script are described below:

!	Indicates a comment.
@ORIGINATE @ANSWER	Labels to begin execution of originate and
	answer mode.
xxxxx	Anything specific to your modem should go
	here. Refer to your modem documentation.
38400	Baud rate.
note “Dialing ˆ 1”	Writes to a log.
write “ATDTˆ1”	Writes to serial driver.
ask...	This line tells the system to prompt for the
	information (in this example for the User ID and
	password). Without this line, you would need
	to hard code the information into the script.
@LABEL 19	Numeric label.
matchstr 1 20...	Match incoming characters. The 20 in this line is
	a label.
matchread 400	Reads input from the serial driver and compares
	the input to the current match string.

F-4 Issue 3
