HP LCS60 -mN, -qN, -vN

LCS60 Configuration and Connection for SLIP Service

SLIP Service Connection Dialstrings

One of the following types of dialstrings (shown with the area/exch/name from the example in Figure 5-1) may be used:

DESTINATION: mlkway/earth/morse.slip

DESTINATION: mlkway/earth/morse.slip..-m512:-q1:-v16

DESTINATION: mlkway/earth/morse.slip..-D

DESTINATION: mlkway/earth/morse.slip..154.12.23.10

The options for these dialstrings are described below:

-mN	Specifies the maximum transmission unit (MTU) that the SLIP
	connection can transport. The default SLIP MTU is 1006; the
	MTU value must satisfy: 296 ≤ N ≤ 1006.
-qN	Specifies whether priority queueing is enabled (1) or disabled
	(0). By default, priority queueing is enabled. In priority queue-
	ing, IP datagrams are marked as either interactive or non-
	interactive; interactive datagrams are always queued in front of
	non-interactive datagrams. The queue is located between the IP
	protocol and the data switch, therefore, priority queueing only
	affects datagrams flowing from the LCS60 to the data switch.
-vN	Specifies the number of Van Jacobson TCP/IP header compres-
	sion slots to use. The default is 16; the number of slots must
	satisfy: 3 ≤ N ≤ 64. (Refer to the section Van Jacobson TCP/IP
	Header Compression in Chapter 1.)
-D	Specifies that the user be assigned an IP address dynamically
	(rather than use his/her reserved IP address) provided a negoti-
	able IP address has been administered in his/her client software
	package. Without the -Doption, the reserved IP address for the	SLIP
	user is assigned provided it exists and is not already in use.	SLIP

Issue 3

5-9
