UNIX System Software Installation

Appendix D

2)All automatic disk configuration options

3)Manual disk configuration

4)Read the disk configuration from the disk(s)

Enter option number of choice: [ 1-4 ] ( 1 )			Return
Final Verification of 1-disk installation				BOOT COMMAND: "bo 0 0"
Device	Disk description		Format?	Space Left
m197_c0d0	see note below		No	29520
Partition	Slice	Size	FS	Block Size
/	m197_c0d0s0	58000	ufs	4K
swap	m197_c0d0s1	300000	-	-
/stand	m197_c0d0s2	25000	bfs	-
/usr	m197_c0d0s3	360000	ufs	4K
/var	m197_c0d0s4	120000	ufs	4K
/home	m197_c0d0s5	100000	ufs	4K
/tftpboot	m197_c0d0s6	22000	s5	2K

1)Proceed with installation using configuration shown

2)Change file system type and return to this screen

3)Change disk formatting and return to this screen

4)Change slice size and return to this screen

Enter option number of choice: [ 1-4 ] ( 1 ) 3

Final Verification of 1-disk installation				BOOT COMMAND: "bo 0 0"
Device	Disk description		Format?	Space Left
m197_c0d0	see note below		Yes	29520
Partition	Slice	Size	FS	Block Size
/	m197_c0d0s0	58000	ufs	4K
swap	m197_c0d0s1	300000	-	-
/stand	m197_c0d0s2	25000	bfs	-
/usr	m197_c0d0s3	360000	ufs	4K
/var	m197_c0d0s4	120000	ufs	4K
/home	m197_c0d0s5	100000	ufs	4K
/tftpboot	m197_c0d0s6	22000	s5	2K

1)Proceed with installation using configuration shown

2)Change file system type and return to this screen

3)Change disk formatting and return to this screen

4)Change slice size and return to this screen

Enter option number of choice: [ 1-4 ] ( 1 ) 1

Note: The Disk Description field above varies depending on the type of drive: 525MB SCSI (FUJITSU M2624) or SEAGATE ST5660N.

13. For both the Fujitsu and Seagate ST5660N drives: The system will ask if you want to install Motif, NCD, and X11 package features. Choose the defaults by entering Return .

D-6

Issue 3
