lcsadm Interface

Name	upgrade
Synopsis	upgrade
Description	This command generates a menu which allows you to per-
	form a remote upgrade of the LCS60. Refer to the Chapter
	9 for complete details of the remote upgrade feature.

Name	viewhosts or viewnets
Synopsis	viewhosts or viewnets
Description	The viewhosts command displays the internet addresses
	and host names of all hosts on a specific network or on all
	networks that are currently in the network database as
	well as IP reserved addresses for SLIP and PPP. viewnets
	displays all networks (names, numbers, and aliases) in the
	database configuration (as found in the /etc/networks file).

Typical Administrative Tasks

This section gives a few examples of tasks the LCS60 Administrator may per- form. For LCS60 service-specific tasks refer to the appropriate chapter: PPP (Chapter 4), SLIP (Chapter 5), ARAP (Chapter 6), gateway (Chapter 7).

Administration

Issue 3

8-21
