lcsadm Interface

Name	flush
Synopsis	flush service-type [service-type ...]
Description	The flush command resets statistics for a service type.
	This command requires root permission.

Name	show
Synopsis	show [service-type ...]
Description	The show command lists statistics on configured services,
	capacities, and current states. Entering show without
	arguments will display statistics for all services.

Name	summary
Synopsis	summary
Description	This command summarizes the service information
	including the number of sessions configured for each
	service and the state of the service. For PPP, this command
	lists the number of IP, AppleTalk, and IPX over PPP
	sessions.

Name	types
Synopsis	types
Description	The types command lists the available service types.

Administration

Manager Directory Commands

The Manager directory (Screen 8-5) provides utilities to obtain information about the LCS60 management (LCM) subsystem components. This directory is not used for standard administration but should only be used for diagnostic administrative purposes.

Issue 3

8-13
