HP LCS60 119

LCS60 Configuration and Connection for PPP Service

==> 2

VIRTUAL (PPP) CONFIGURATION PARAMETERS

1 Configure/Display Network Address

Enter Menu Selection

[ ? for help, q to quit, RETURN for menu ] ==> 1

Current Virtual Network Number .....

< Undefined >

Enter an IPX Network Number

[ Type q to quit or ? for help ] ==> 57

Network < 57 > is already configured for your Ethernet Interface.

VIRTUAL (PPP) CONFIGURATION PARAMETERS

1 Configure/Display Network Address

Enter Menu Selection

[ ? for help, q to quit, RETURN for menu ] ==> q

CAUTION: Please refer to the I&A Guide for instructions about configuring this feature.

IPX CONFIGURATION MANAGEMENT

1Ethernet interface configuration parameters

2Virtual (PPP) interface configuration parameters

3Display all Parameters

Enter Menu Selection

[ ? for help, q to quit, RETURN for menu ] ==> 3

The LCS60 IPX Parameters are configured as follows:

Ethernet Network Number .....	< 1562		>
Virtual Network Number ......	<	57 >
Ethernet Frame Type .........	<	Ethernet II >

CAUTION: Please refer to the I&A Guide for instructions about configuring this feature.

PPP

IPX CONFIGURATION MANAGEMENT

1Ethernet interface configuration parameters

2Virtual (PPP) interface configuration parameters

3Display all Parameters

Enter Menu Selection
