User Information

LAN to LCS60 to Data Switch

To transfer files, using uucp, from an Ethernet host to the LCS60 to a host attached to a data switch, the system administrator must configure a service port for socket service.

Note: Configuration of the service port for socket service requires super user permission.

To configure the service, the administrator can assign a PDD (of the destination to which you will be transferring files) to the service port. (If a PDD is not assigned, once connected, the system will return the LCS60 call address prompt for the user to enter the destination desired.) The screen below shows an exam- ple based on Figure 7-1 for the Ethernet host topper connected to the LCS60 morse to send files over port 2981 to host watson.

#lcsadm

Top> # config srvports

TCP-TO-ASYNCHRONOUS GATEWAY SERVICE CONFIGURATION MENU

1. Display/Change the LCS60 call address prompt

2. Add a service port

3. Delete a service port

4. Change/modify a service port

5. Display service ports

Enter Menu Selection

[ Type q to QUIT or ? for HELP ] ==> 2

Enter service port number

[ Type q to QUIT or ? for HELP ] ==> 2981

Enter service type "telnet", "socket", or "directory" for port 2981 [ Type q to QUIT or ? for HELP ]

==> socket

Enter Pre-Defined call address or dash (-) for no call address

[ Type q to QUIT, ? for HELP, or press RETURN for default of "-" ] ==> mlkway/earth/watson

Enter TCP window size

[ Type q to QUIT, ? for HELP, or press RETURN for default of "1024" ] ==> 8192

Enable the LCS60 NOHUP (no hangup) feature for this port?

Gateway

Issue 3

7-15
