lcsadm Interface

Administration

Name	start
Synopsis	start [? ⎪ dkhost ⎪ ipx ⎪ tcpip ⎪ atalk ⎪ slip ⎪ ppp ⎪ snmp ⎪
	routed ⎪ asytcp ⎪ tcpasy ⎪ arap ⎪ all]
Description	The start service/protocol command starts the named service
	or protocol. When invoked without options, start will list
	the services/protocols that are running. Services and pro-
	tocols can be started individually or all at once using the
	all option. all will start all protocols and services config-
	ured to be started at boot time (through the lcsadm config
	protocol command). start requires root permission.
	dkhost indicates the CommKit Host Interface Software.
	The start command may start more services/protocols
	than specified on the command line due to the dependen-
	cies of the protocols and services. Table 8-1 shows the
	dependencies for the start and stop commands.

Name	stop
Synopsis	stop [? ⎪ dkhost ⎪ ipx ⎪ tcpip ⎪ atalk ⎪ slip ⎪ ppp ⎪ snmp ⎪
	routed ⎪ asytcp ⎪ tcpasy ⎪ arap ⎪ all]
Description	The stop command (requires root permission) stops the
	named service or protocol. Services/protocols can be
	stopped individually or all at once (all). The all option
	will stop all protocols and services that are running when
	stop is executed. This command may stop more
	services/protocols than specified on the command line
	due to the dependencies of the protocols and services.
	stop requires root permission. Table 8-1 shows the depen-
	dencies for the start and stop commands.

8-6

Issue 3
