Installing the LCS60

Remove the rubber caps from the optical fiber cable that runs from the receiver side of the LCS60, and connect the optical fiber cable to the transmitter side (bottom connector) of the CPM-HS module in the data switch.

5. Set the MODE toggle switch on the CPM-HS faceplate to ENABLE.

6. Set the Loopback switch on the CPM-HS paddleboard to NORM.

Note: If the cable is installed backwards, no harm will be done when powering up.

Configuration of the Lucent Technologies Data Switch

–LCS60

Configuration of the CPM-HS module in the data switch is done in the same way as a CPM-HS module connected to a UNIX System host. The number of channels should be the same as the number of channels with which the LCS60 is con- figured, 512.

The first local address entered must match the first IP Network Security Group's name. Subsequent local addresses should match the other IP Security Group names entered into the LCS60 configuration database. The LCS60 supports up to four IP Network Security Groups. The first local address should be the same as the node name of the LCS60. Additional information on creating the local address group, and CPM-HS entries can be found in the Lucent Technologies data switch documentation.

After the CPM-HS module is plugged into the data switch, the CPM-HS module must be configured from the data switch console. The Network Administrator enters the group name and local address for the LCS60, and configures the CPM-HS module. The following tasks are performed at the data switch console:

Hardware

Enter group name

Define the local address for the LCS60

Configure the CPM-HS module.

Sample dialogues (see also Figure 3-1) for these tasks are described below.
