Working with Adapters

1) To	remove		a card support from.1/ ora	slottorage location.2/,
gently release the card .support3/ and				slidetab the card support away
from		the	system board until the	card support is free.

2) To	insert	a card	support in		a	slot or a storage location, pla
support in		the slot	or	storage		opening and slide the card su
the	system	board	until	the	tab	clicks into place.

c. If you removed the card support bracket from the server, rep server now.

5. Touch the static-protective packageunpaintedto metalany surface on the server; then, remove the adapter from the package.

6. Install the adapter:

a. Carefully	grasp the adapter and align it	with	the expansion slot
the card	support bracket if a full-length	adapter).
b. Press the	adapterfirmly into the connector until	fully	seated.

52 Netfinity 5000 Server Hardware Information and Procedures
