Agilent 35670A

Replacing Assemblies



To remove memory

To remove memory

1 Remove A7 CPU assembly (see ‘’To remove CPU’’). Remove optional A9 NVRAM assembly (see ‘’To remove NVRAM’’).

2 Using a T-10 torx driver, remove the eight screws from the A8 Memory assembly.

6-13
