Backup Components 781

Specify Devices to Backup Step

This step of the wizard is only displayed if you have selected the Custom option on the Backup Type step. If you selected devices in the network before starting the Device Backup, those devices are listed on this page by default as shown in Figure 425

Figure 425 Specify Devices to Backup

You can add devices to the list and remove devices from the list box provided, using the Add and Remove buttons.

Specify Telnet Login Information Step

The Specify Telnet Login Information step is only displayed if one or more of the devices that you have selected for backup require Telnet login information, in order to perform the backup operation, as shown in Figure 426.

Image 785
