Toshiba G7 M ONITOR S, SPECIAL CONTROL P

G7 ASD Operation Manual 57

MONITOR SETUP Trip Monitor from ASD Fourth Most Recent N/A

Scrolling Monitor Select Scrolling Monitor Select N/A

SPECIAL CONTROL

PARAMETERS Frequency Control

Start Frequency F240

End Frequency F243

Run Frequency F241

Run Frequency Hysteresis F242

Jump Frequencies Jump Frequency Bandwidth Settings F271

Jump Frequency Processing Selection F276

Carrier Frequency PWM Carrier Frequency Setting F300

Accel/Decel #1 – #4

Settings

Accel/Decel/Pattern #1 Co n fi g ur at ion F009

Accel/Decel/Pattern #2 Co n fi g ur at ion F500

Accel/Decel/Pattern #3 Co n fi g ur at ion F510

Accel/Decel/Pattern #4 Co n fi g ur at ion F514

Accel/Decel Special

S-Pattern Lower Limit Adjustment F506

S-Pattern Upper Limit Adjustment F507

Accel/Decel Time Lowe r Limit F508

Accel/Decel Switching Frequency #1 F505

Accel/Decel Switching Frequency #2 F513

Accel/Decel Switching Frequency #3 F517

Display Resolution F704

Crane/Hoist Load

High-Speed Operation at Light Load F330

Light-load High-speed Operation Switching

Lower Limit Frequency F331

Light-load High-speed Operation Load

Waiting Time F332

Light-load High-speed Operation Load

Detection Time F333

Light-load High-speed Operation H eavy Load

Detection Time F334

Switching Load Torque During Forward Run F335

Heavy Load Torque During Acceleration in

the Forward Direction F336

Heavy Load Torque During Deceleration in

the Forward Direction F337

Switching Load Torque During Reverse Run F338

Heavy Load Torque During Acceleration in

the Reverse Direction F339

Heavy Load Torque During Deceleration in

the Reverse Direction F340

Frequency for Automatic High-speed

Operation at Light Load F341

Backlash Setup Not available at the time of this release. N/A

Program Menu Navigation

Primary Menu Sub Menu Parameter Nam e Parameter

Number

Contents
