System Setup, Auxiliary Area Allocations, and Built-in I/O Allocations					Appendix C

Address	Bits	Name		Function		Controlled
						by
A609	00	High-speed	Target Compar-	Same as for high-speed counter 1.		Module
		counter 2 status	ison In-
			progress Flag

	01		PV Overflow/
			Underflow Flag

	02		Reserved

	03		Phase Z Input
			Reset Flag (ON
			for one cycle)

	04		Absolute No. of
			Rotations Read
			Error Flag

	05		Absolute No. of
			Rotations Read
			Completed
			Flag
	06		Measuring Flag
			(measurement
			mode 1 or 2)
	07		High-speed
			Counter Oper-
			ating Flag
	08		Count Latched
			Flag

	09 to 11		Reserved

	12		Absolute Off-
			set Preset
			Error Flag
	13 to 15		Reserved

331
