F931 F935

My Function Time Data 4

Program ⇒ My Function ⇒ My Function Data

This parameter is used to set the response delay of the My Function Time Data 4 terminal.

The applied discrete input signal must be present at the input terminal of the H9 ASD for the time setting here for a system response.

Discrete terminal input activation that does not equal or exceed this setting will be ignored.

Direct Access Number — F931

Parameter Type — Numerical

Factory Default — 0.01

Changeable During Run — Yes

Minimum — 0.01

Maximum — 600.00

Units — Seconds

My Function Time Data 5

Program ⇒ My Function ⇒ My Function Data

This parameter is used to set the response delay of the My Function Time Data 5 terminal.

The applied discrete input signal must be present at the input terminal of the H9 ASD for the time setting here for a system response.

Discrete terminal input activation that does not equal or exceed this setting will be ignored.

Direct Access Number — F932

Parameter Type — Numerical

Factory Default — 0.01

Changeable During Run — Yes

Minimum — 0.01

Maximum — 600.00

Units — Seconds

My Function Count Data 1

Program ⇒ My Function ⇒ My Function Data

This parameter is used to set the pulse-count threshold value used to trigger the discrete output COUNT1 (ON Timer).

COUNT1 (ON Timer) outputs a 1 upon reaching the setting of this parameter.

Direct Access Number — F933

Parameter Type — Numerical

Factory Default — 0

Changeable During Run — Yes

Minimum — 0

Maximum — 9999

Units — Pulses

My Function Count Data 2

Program ⇒ My Function ⇒ My Function Data

This parameter is used to set the pulse-count threshold value used to trigger the discrete output COUNT2 (ON Timer).

COUNT2 (ON Timer) outputs a 1 upon reaching the setting of this parameter.

Direct Access Number — F934

Parameter Type — Numerical

Factory Default — 0

Changeable During Run — Yes

Minimum — 0

Maximum — 9999

Units — Pulses

Input Function Target 1

Program ⇒ My Function ⇒ My Function Unit 4

This parameter plays a role in the setup of the My Function feature by selecting the functionality of the programmable Input Function Target 1 terminal.

This setting assigns the function of the programmable Input Function Target 1 terminal to any one of the user-selectable functions listed in Table 7 on pg. 240, Table 8 on pg. 241, or Table 10 on pg. 243.

See F977 for more information on this parameter.

Direct Access Number — F935

Parameter Type — Selection List

Factory Default — 0 (Disabled)

Changeable During Run — Yes

222 H9 ASD Installation and Operation Manual
