Program Mode Menu Navigation
Primary Menu | Sub Menu | Parameter Name | Parameter | |
Number | ||||
|
|
| ||
|
|
|
| |
|
|
|
| |
SPECIAL | Jump Frequencies | Jump Frequency 3 | F274 | |
|
|
| ||
| Jump Frequency 3 Bandwidth | F275 | ||
|
| |||
|
|
|
| |
|
| Operation Command Clear Selection With Standby | F719 | |
|
| Terminal Off | ||
|
|
| ||
|
|
|
| |
|
| Panel Stop Pattern | F721 | |
|
|
|
| |
|
| Panel Torque Command | F725 | |
|
|
|
| |
| Operation Panel | Panel Tension Torque Bias | F727 | |
|
|
| ||
|
|
| ||
| Parameters | Panel Load Sharing Gain | F728 | |
|
|
|
| |
|
| Panel Override Multiplication Gain | F729 | |
|
|
|
| |
|
| Panel Frequency Lockout | F730 | |
|
|
|
| |
|
| Panel Emergency Off Lockout | F734 | |
|
|
|
| |
|
| Panel Reset Lockout | F735 | |
|
|
|
| |
|
| Traverse Selection | F980 | |
|
|
|
| |
|
| Traverse Acceleration Time | F981 | |
| Traverse |
|
| |
| Traverse Deceleration Time | F982 | ||
|
|
|
| |
|
| Traverse Step | F983 | |
|
|
|
| |
|
| Traverse Jump Step | F984 | |
|
|
|
| |
MOTOR |
| Motor Set #2 Base Frequency | F170 | |
|
|
|
| |
| Motor Set #2 | Motor Set #2 Base Frequency Voltage | F171 | |
|
|
| ||
| Motor Set #2 Manual Torque Boost | F172 | ||
|
| |||
|
|
|
| |
|
| Motor Set #2 Overload Protection Level | F173 | |
|
|
|
| |
|
| Motor Set #3 Base Frequency | F174 | |
|
|
|
| |
| Motor Set #3 | Motor Set #3 Base Frequency Voltage | F175 | |
|
|
| ||
| Motor Set #3 Manual Torque Boost | F176 | ||
|
| |||
|
|
|
| |
|
| Motor Set #3 Overload Protection Level | F177 | |
|
|
|
| |
|
| Motor Set #4 Base Frequency | F178 | |
|
|
|
| |
| Motor Set #4 | Motor Set #4 Base Frequency Voltage | F179 | |
|
|
| ||
| Motor Set #4 Manual Torque Boost | F180 | ||
|
| |||
|
|
|
| |
|
| Motor Set #4 Overload Protection Level | F181 | |
|
|
|
| |
| PM Motor | PM Motor Constant 1 (d axis inductance) | F498 | |
|
|
| ||
| PM Motor Constant 2 (q axis inductance) | F499 | ||
|
| |||
|
|
|
|
58 | H9 ASD Installation and Operation Manual |
